iMOW EFL181
$27,900 +GST
The EFL 181 Li-Ion forklift is the next generation, entry-level forklift from EP Equipment.
Integrated charger for simple charging at every standard power outlet.
The Li-Ion battery as a maintenance-free power source as well as the big front tyres that allow usage on uneven floors and in the yard.
It can be charged straight from a 15AMP power point.
- Load Capacity : 1800 kg
- Lifting Height : 4800mm
- Attachment Opt. : Side Shifter
- Battery Capacity : 48V150AH
- Battery Type : Li-Ion Battery
- Charger Type : Built-in Charger
- Tyre Options : Solid
RRP $29,900+GST – Now $27,900+GST ( $30,690 Inc. GST)
*Also available with many variations for forklift capacity and mast lift height.
* For Product Specs, please click “SPECS” next to “FEATURES” under picture above.
1.3 Drive unit Electrics
1.4 Operator type seated
1.5 Rated capacity Q t 1.8
1.6 Load center distance c mm 500
1.8 Load distance centre of drive axle to fork x mm 405
1.9 Wheelbase y mm 1260
2.1 Service weight include battery kg 3030
2.2 Axle loading, laden driving wheels /steering wheels kg 4395/435
2.3 Axle loading, unladen driving wheels /steering wheels kg 1300/1730
3.1 Tyre type,driving wheels /steering wheels solid rubber
3.2 Tyre size, driving wheels diameter×width mm 6.5-10
3.3 Tyre size, steering wheels diameter×width mm 5.00-8
3.5 Wheels, number driving/steering (x=drive wheels) mm 2x/ 2
4.1 Tilt of mast/fork carriage forward/backward α/ β (°) 6/ 10
4.2 Height, mast lowered h1 mm 2000
4.3 Free lift load backrest h2 mm 130
4.4 Lift height h3 mm 4800
4.5 Height, mast extended h4 mm 4028
4.7 Height of overhead guard (cabin) h6 mm 2080
4.8 Seat height h7 mm 1060
4.12 Tow center of pin height h10 mm 370
4.19 Overall length l1 mm 2935
4.20 Length to face of forks l2 mm 2015
4.21 Overall width b1/ b2 mm 1080
4.22 Fork dimensions s/ e/ l mm 40×100×920
4.23 Fork carriage class/type A, B 2A
4.24 Fork carriage width b3 mm 1040
4.31 Ground clearance, laden, below mast m1 mm 115
4.32 The minimum ground clearance of frame m2 mm 120
4.34.1 Aisle width for pallets 1000 × 1200 crossways Ast mm 3525
4.34.2 Aisle width for pallets 800 × 1200 lengthways Ast mm 3725
4.35 Turning radius Wa mm 1920
5.1 Travel speed, laden/ unladen km/ h 8.5/9
5.2 Lifting speed, laden/ unladen m/ s 0.25/ 0.3
5.3 Lowering speed, laden/ unladen m/ s 0.43/ 0.45
5.6 Max. drawbar pull, laden/unladen (time) N 10000
5.7 Gradeability, laden/unladen % ——
5.8 Max. gradeability, laden/unladen % 10.5/15
5.9 Service brake type Hydraulic+ Mechanical
5.10 park brake type Mechanical6.1 Drive motor rating S2 60 min kW 6
6.2 Lift motor rating at S3 15% kW 7.5
6.3 The maximum allowed size battery mm 750X530X210
6.4 Battery voltage/nominal capacity K5 V/ Ah 48V150AH
6.5 Battery weight kg 115
8.1 Type of drive unit AC
10.7 Sound pressure level at the driver’s ear dB (A) 75
